Tyre Mounted Gantry Crane | Mobile Lifting Solution for Track-Free Operations

FEM/CMAA/ISO 4301 Certified with 1,200T Capacity & AI-Driven Synchronization

Brand: Henan Hengkun Crane Co., Ltd.
Applications: Factories, warehouses, steel mills, logistics centers, and industrial facilities requiring mobile, heavy-duty lifting solutions for machinery, raw materials, and large components.

---

Product Overview

Henan Hengkun’s  Tyre-Mounted Gantry Cranes revolutionize heavy lifting with zero-track infrastructure requirements and multi-crane millimeter-level synchronization. Engineered for ports, construction sites, and mega-project logistics, our cranes deliver 20-1,200T lifting capacity with industry-leading 4% gradeability on gravel, concrete, and uneven terrains.

---

Core Engineering Breakthroughs

Triple Mobility Advantage

1. All-Terrain Adaptability
→ Pneumatic/solid tyre options (DIN 7801)
→ Articulated frame eliminates internal stresses on uneven ground

2. Smart Steering System
→ 4-mode steering: Ackermann/Crab/360° Rotation/Diagonal
→ ±0.5° wheel alignment accuracy

3. Compact Transport
→ Auto-folding boom (optional)
→ 35% reduced stowed length

Intelligent Lifting Architecture

• NHA Euro Hoist Integration:
  → Direct-drive motor-brake system (ISO 12425)
  → Dual-disc brakes + auxiliary caliper

• Structural Integrity:
  → Q355B steel (EN 10025)
  → UT/MT tested welds (ISO 5817 Level B)

---

Technical Specifications

Common Parameters

• Gradeability: 4% loaded / 8% unloaded

• Turning Radius: Zero (360° spot turn)

• Surface Treatment:
  → SA 2.5 blast cleaning (ISO 8501-1)
  → 280μm Zn-rich epoxy + PU topcoat (ISO 12944 C5-M)

---

Smart Control Ecosystem

► MULTI-CRANE SYNCHRONIZATION:

• ≤10mm position variance

• Real-time load sharing

► ANTI-SWAY AI:

• 95% swing reduction at 20m/min

• Auto-positioning ±2mm

► SAFETY INTELLIGENCE:

• Zero-speed hovering (anti-droop)

• Zone-restricted load limiting

• Impact prevention system

---

Performance Comparison

Capability	TM-Series	Traditional Gantry
Mobility	Immediate deployment	Weeks of track installation
Steering Flexibility	4 modes (360° rotation)	Fixed linear movement
Terrain Adaptation	Gravel/mud/2% unevenness	Level concrete only
Multi-Crane Lift	≤10mm sync precision	Manual coordination

---

Certified Components

System	Standard	Certification
Structural	FEM 1.001 Class D	ISO 8686-1 load calc
Electrical	IEC 60204-32	IP55 cabinets + HVAC
Hoist	ISO 12425	Dual-brake EN 13155
Welding	ISO 15614-1	AWS D14.1 Class I

---

Smart Functions Overview

Feature	Benefit	Precision
Micro-Speed Mode	0.1m/min positioning	±1mm final placement
Creeper Control	5cm step movement	Critical alignment
Speed Extensions	4-range velocity profiles	35% cycle time reduction
IoT Connectivity	Remote diagnostics	Predictive maintenance

---

Yangtze River Bridge Project
*4×800T Tyre-Mounted Gantry Cranes synchronizing 1,200T segments:

• 10mm positional accuracy achieved

• 3-day installation vs 3-week schedule*

---

Global Compliance

• Safety: EN 13000 / ASME B30.2

• Structural: ISO 22986 (wind load)

• Corrosion: ISO 12944 C5-M (25-year)

• Cybersecurity: IEC 62443-3-3

---

Application-Specific Kits

Environment	Configuration
Port Operations	Salt-resistant coating + radar collision
Wind Farm	10% gradeability upgrade
Indoor Factory	Zero-emission electric drive
Mining	Reinforced tyre puncture protection

---

Service & Certifications

• Global Compliance: CE, ISO 9001, ISO 14001, FEM.

• Installation: Site assessment, assembly, and load testing.

• Warranty: 12 months (extendable) with 24/7 technical support.

• Training: Operator safety programs and hydraulic system maintenance.

---

Why Choose Us?
As a leading Chinese manufacturer, we deliver industrial-grade hydraulic gantry cranes that balance mobility, power, and precision. Our cranes are rigorously tested to meet global safety standards, offering cost-effective solutions for demanding industrial lifting tasks.

Request a Custom Solution – Elevate your material handling with hydraulic innovation and mobility!
