EN 280/ANSI A92.20 Certified with Fuzzy Logic Crawler Control & 360° Zero-Turn Rotation
Brand: Henan Hengkun Crane Co., Ltd.
Applications: Construction sites, forestry, urban landscaping, utility maintenance, and projects requiring ultra-stable, low-impact access on soft, uneven, or sensitive terrain such as lawns, gravel, and slopes.
Henan Hengkun's SC-Series Spider Lifts redefine access in complex environments with mm-accurate crawler positioning and 20° slope operation. Engineered for historical renovations, mountain installations, and indoor construction, these lifts deliver 28m working height at just 1.2m stowed width through patented telescopic crawlers and AC direct-drive technology.
Sub-Millimeter Movement:
→ Laser-guided step control (0.5mm resolution)
→ Auto-surface adaptation (gravel/mud/ice)
360° Zero-Turn Rotation:
→ Independent track speed control
1. One-Button Leveling:
→ 3-second auto deployment on 20° slopes
→ Hydraulic outriggers with load sensors
2. Adjustable Ground Contact:
→ 80° leg angle adjustment
| Model | Platform Ht. | Operating Radius | Crawler Length | Speed | Weight |
|---|---|---|---|---|---|
| S14C | 14m | 6.2m | 5.2m | 3.0km/h | 1,900kg |
| S16C | 16m | 7.2m | 5.2m | 2.5km/h | 2,200kg |
| S19C | 19m | 9.5m | 5.35m | 3.0km/h | 2,850kg |
| S22C | 22m | 11m | 5.5m | 2.2km/h | 3,160kg |
| S26C | 26m | 12.5m | 6.5m | 3.0km/h | 4,000kg |
Shared Performance Features
Lift Capacity: 200kg (2 persons)
Jib Rotation: 90°-120°
Gradeability: 30% travel / 20% working
Power: 48V/420Ah LiFePO₄ (8hr+ runtime)
Width Adjustment:
→ 0.8m (narrow) to 1.8m (stabilized)
→ Ideal for doorway access
Obstacle Climbing:
→ 300mm vertical step
→ 400mm trench crossing
Range Extender:
→ 5kVA gasoline generator (unlimited runtime)
Solar Charging:
→ 400W roof-mounted panels
Regenerative Descent:
→ 15% energy recovery
Guatemala marble factory case
*S22C operating in 4.2m narrow aisles:
0.5mm precision stone placement
Structural: FEM 1.001 Category B
Electrical: IEC 60335-1 (Indoor Use)
Environmental: Stage V emission compliance
Safety: ISO 16368 Level 3
Global Compliance: CE, ANSI, ISO, and OSHA standards.
Installation: On-site training and operational safety checks.
Warranty: 12 months (extendable) with 24/7 technical support.
Maintenance: OEM spare parts and predictive maintenance programs.
Why Choose Us?
As a leading Chinese manufacturer, we deliver cost-effective rubber track spider lifts that blend European engineering precision with rugged adaptability. Rigorously tested for reliability in extreme environments, our lifts are trusted globally for urban landscaping, utility maintenance, and eco-sensitive projects.
Request a Custom Solution – Navigate challenging terrain with eco-friendly, precision-engineered access!
