Brand: Henan Hengkun Crane Co., Ltd.
Applications: Warehouses, retail stores, airports, theaters, and light industrial facilities requiring lightweight, corrosion-resistant access solutions for maintenance, stock management, and indoor/outdoor elevated tasks.
Henan Hengkun’s Aluminum Hydraulic Scissor Lifts revolutionize access solutions with aircraft-grade aluminum construction, delivering 60% weight reduction versus steel platforms while maintaining 300kg load capacity. Engineered for electronics factories, cleanrooms, and historical site maintenance, these lifts eliminate floor damage risks and operate emission-free.
6061-T6 Aluminum Frame:
Anodized finish (25μm) for corrosion resistance
TIG-welded joints (AWS D17.1 certified)
Compact Stowed Profile:
760mm width fits standard doorways
Folding guardrails reduce height by 45%
Sealed Power Unit:
24V DC brushless motor
160 bar gear pump with pressure compensation
Stepless Control:
0-18 m/min lift speed adjustment
±1mm platform stability
| Parameter | Specification |
|---|---|
| Max. Working Height | 4–12 meters (platform height) |
| Platform Dimensions | 0.7 x 1.5 m – 1.2 x 2.5 m (WxL) |
| Load Capacity | 150–300 kg |
| Lift Speed | 0.1–0.3 m/s (adjustable) |
| Power Source | Manual hydraulic pump, 24V DC, or 220V AC |
| Travel Wheels | 4–6 swivel casters (2–4 with brakes) |
| Weight | 150–700 kg (depending on height) |
| Ground Clearance | 50–100 mm (low-profile design) |
| Protection Grade | IP54 (indoor/outdoor use) |
| Ambient Temperature | -10°C to +50°C |
| Certifications | CE, ISO 9001, ANSI/SAIA A92.20 |
1. Non-Conductive Safety
Dielectric rating: 30kV dry / 10kV wet
Static dissipative tires (106–108 Ω)
Spark-proof electrical system
2. Precision Maneuverability
90° pivot steering
Dual front/rear drive motors
Automatic tilt compensation (±3°)
3. Environment-Specific Packages
| Application | Specialized Configuration |
|---|---|
| Semiconductor Fabs | ISO Class 4 cleanroom certification |
| Museums | Non-marking PU tires + rubber matting |
| Food Processing | FDA-compliant stainless steel options |
| Explosive Zones | ATEX Zone 22/23 (dust ignition proof) |
Dual Hydraulic Valves: Independent flow control
Emergency Descent: Manual pump override
Tilt Sensors: Auto-stop at >5° inclination
Edge Protection: Retractable toe guards
Compliance:
EN 280:2013
ANSI/SAIA A92.20-2021
IEC 60529 IP65
| Parameter | Aluminum | Conventional Steel |
|---|---|---|
| Weight | 1,150 kg | 2,900 kg |
| Floor Loading | 15 kPa | 35 kPa |
Self-Lubricating Bushings: 10,000-hour service interval
Modular Hydraulic Cartridge: Field replacement in <30 min
Diagnostic System
LuoYang Museum Maintenance Project
*6×AH-10 units operating on 20th-century marble floors:
Zero surface damage over 3 years
Why Choose Us?
As a leading Chinese manufacturer, we deliver cost-effective aluminum scissor lifts that prioritize safety, portability, and corrosion resistance. Rigorously tested for reliability in retail, warehousing, and light industrial applications, our lifts are trusted globally for their lightweight design and smooth hydraulic performance.
Request a Lightweight Solution – Elevate efficiency with corrosion-free, space-saving technology!
