Floodgate Gantry Crane

Product Item : Floodgate Gantry Crane
Category： Gantry Crane
Submersion & Corrosion Resistance:IP68 Electrical Systems | Marine-Grade Aluminum Alloy (EN AW-5083) | Salt Spray Rating: 2,000+ Hours
Dynamic Load Stabilization for Irregular Shapes:AI Load Centering (±5mm Tolerance) | Variable Rigging Points (4-8 Hooks) | Max Tilt Compensation: 10°
Emergency Flood Response Mode: Quick-Release Mechanisms (≤30s) | Night Vision Cameras | Wind Resistance: 20m/s
Precision Gate Alignment & Locking：Laser-Guided Positioning (±2mm) | Hydraulic Pin Locking System | Sealing Pressure Sensors (0-50kPa)
INQUIRY EMAIL

Floodgate Gantry Crane

Brand: Henan Hengkun Crane Co., Ltd.
Applications: Dam maintenance, flood control systems, hydropower stations, sluice gates, and water conservancy projects requiring heavy-duty, corrosion-resistant lifting solutions for gate installation, removal, and emergency operations.

Product Overview

Our Floodgate Gantry Crane is specifically engineered for harsh aquatic environments, combining robust construction, anti-corrosion technology, and precise control to handle massive floodgates, sluice gates, and hydraulic structures. Designed for capacities up to 500 tonnes, this crane ensures reliability in extreme weather and high-moisture conditions, critical for flood prevention and water management infrastructure.

Key Features & Benefits

Corrosion-Resistant Design
- Marine-grade coatings (ISO 12944 C5-M) and stainless steel components resist saltwater, humidity, and chemical exposure.
- IP68-rated motors and waterproof electrical systems for submerged or splash zones.
High Stability & Precision
- Reinforced double girder structure (FEM 4m class) minimizes deflection during gate alignment.
- Laser-guided positioning (±3mm accuracy) and anti-sway systems for safe load placement.
Adaptability to Harsh Conditions
- Storm-proof design withstands winds up to Beaufort Scale 12 and temperatures from -30°C to +60°C.
- Customizable leg heights for uneven terrain or elevated platforms near water bodies.
Energy Efficiency & Safety
- Regenerative braking and variable frequency drives (VFD) reduce energy consumption by 25–30%.
- Dual fail-safe brakes, overload protection, and emergency power backup.
Modular Assembly
- Prefabricated components enable rapid on-site installation in remote or flood-prone areas.

Technical Specifications

Parameter	Specification
Lifting Capacity	10–500 tonnes
Span	20–80 meters (customizable)
Lifting Height	Up to 50 meters
Work Class	FEM 4m / ISO A7
Traveling Speed	2–20 m/min (VFD-controlled)
Operating Voltage	380–690V AC, 50/60Hz or diesel generator
Protection Grade	IP68 (critical components), IP66 (controls)
Wind Resistance	Beaufort Scale 12
Ambient Temperature	-30°C to +60°C
Corrosion Standard	ISO 12944 C5-M

Customization Options

Special coatings: Anti-biofouling or epoxy-polyurethane hybrid finishes.
Automation: Remote control, IoT sensors for water level monitoring, or integration with SCADA systems.
Attachments: Hydraulic grabs, vacuum lifters, or custom hooks for gate handling.
Mobility: Rail-mounted, rubber-tired, or stationary configurations.
Safety add-ons: Submersible lighting, emergency flood response kits, or anti-icing systems.

Service & Certifications

Global compliance: CE, ISO 9001, ISO 14001, and IECEx (for hazardous zones).
Turnkey solutions: Site survey, installation, and operator training for floodgate operations.
Warranty: 24 months (extendable) with 24/7 global technical support.
Maintenance: Lifetime access to OEM parts and corrosion inspection programs.

Why Choose Us?
As a leading Chinese manufacturer, we deliver marine-grade gantry cranes that meet the rigorous demands of water conservancy and flood control projects. Our cranes are certified for safety and durability, combining European engineering standards with cost-effective production to ensure reliability in critical infrastructure operations.

Request a Quote – Safeguard your water management systems with precision-engineered lifting technology!
